INDENT CRIMP

(Pivot & Parallel Jaw Style)

F CRIMP

(Stamped & Formed)

4 / 8 INDENT CRIMP

COMPRESSION CRIMP

MODULAR DATA CRIMP

HYDRAULIC CRIMP (TMS)

Indent crimps use an indentor ram to deform the barrel This configuration's advantage is that it covers a broad range of sizes.

CONFINED CRIMP

The F Crimp is used to close the barrel to confine the individual strands. The quality of this crimp is excellent overall.

The Confined Crimp provides the best overall

crimp. It's the shape of a hexagon, enclosed

'C' or a confined quad. The advantage of these crimps is uniformity of compression of individual strands and outer appearance.

The 4 / 8 Indent crimp is perfect for wire

ranges 26 through 14 AWG.

Compression Crimpers

are ideal for use with

coax cables and a

variety of connectors

including:

     - F

     - BNC

     - RCA

DOES YOUR JOB CALL FOR A TOOL OUTSIDE THE BUDGET? DO YOU NEED A CRIMPER FOR A ONE TIME PROJECT? RENTAL TOOLS ARE THE PERFECT SOLUTION

A Modular Data Crimp assists with installation of modular plugs and works with data networking cables and phone circuits.

The Hydraulic Crimp securely crimps fittings at the ends of hydraulic hoses.

10

Telemaster Modular Plug

Ratchet Crimper Tool

Part # II30-696

• Size: RG-11 and RG-45 Plugs

• Manufacturer: IDEAL

• Crimp Style: Modular Data Crimp

9

Part # HDT-48-00PN

• Size: Solid Pins size 12 - 20

• Manufacturer: Deutsch

• Crimp Style: 4 Indent Crimp

Handheld Pneumatic

Crimper

8

Crimper for Insulated

Terminals

Part # CSA-0760

• Size: 10 - 22 AWG

• Manufacturer: Pressmaster

• Crimp Style: Confined Crimp

7

Mobile Tool Frame for use

with 4300 Die Sets

Part # MCT FRAME

• Size: *Multiple (4300 Die Sets)

• Manufacturer: Pressmaster

• Crimp Style: Parallel Confined Crimp

6

CimpAll Crimp Tool

Part # PA8000

• Size: Interchangeable Die Sets

• Manufacturer: Greenlee

• Crimp Style:  *Depends of the Die Set

5

Omniseal ProXL

Compression Tool

Part # II30-793

• Size: Works with F, BNC, RCA, RG-11, &

            Mini Connectors. RG-6, RG-59, &

            RG-11 Cables

• Manufacturer: IDEAL

• Crimp Style: Compression Crimp

Field Service Crimper

Part # HDT-1561

• Size: Size 12, 16, & 20 Solid Contacts

• Manufacturer: Deutsch

• Crimp Style:  Single Indent Crimp

4

3

Mil-Spec Crimp Tool Frame

Part # AF8

• Size: Requires Turret Heads Size

            12 - 26 AWG

• Manufacturer: DMC

• Crimp Style: 8 Indent Crimp

2

Production Grade Hand

Crimper

Part # HDT-50-00

• Size: Size 12 - 20 Solid Contacts

• Manufacturer: Deutsch

• Crimp Style:  Single Indent Crimp

Hand Crimp Tool

Part # HDT-48-00

• Size: 12 - 20 AWG

• Manufacturer: Deutsch

• Crimp Style: 8 Indent Crimp

1
