TOP 5 CRIMPER BRANDS



A WIDE VARIETY OF INDUSTRY LEADING WIRE CRIMPING TOOLS AVAILABLE AT WIRECARE.COM

INDENT CRIMP

(Pivot & Parallel Jaw Style)

F CRIMP

(Stamped & Formed)

4 / 8 INDENT CRIMP

COMPRESSION CRIMP

MODULAR DATA CRIMP

HYDRAULIC CRIMP (TMS)

Indent crimps use an indentor ram to deform the barrel This configuration's advantage is that it covers a broad range of sizes.

CONFINED CRIMP

The F Crimp is used to close the barrel to confine the individual strands. The quality of this crimp is excellent overall.

The Confined Crimp provides the best overall

crimp. It's the shape of a hexagon, enclosed

'C' or a confined quad. The advantage of these crimps is uniformity of compression of individual strands and outer appearance.

Indent Crimp Diagram
F Crimp Diagram
Confined Crimp Diagram

TOP 7 WIRE CRIMP STYLES

4/ 8 indent crimp diagram

The 4 / 8 Indent crimp is perfect for wire

ranges 26 through 14 AWG.

Compression Crimp Diagram

Compression Crimpers

are ideal for use with

coax cables and a

variety of connectors

including:

     - F

     - BNC

     - RCA



TOP 10 CRIMPERS

9

Telemaster Modular Plug

Ratchet Crimper Tool



Part # II30-696

• Size: RG-11 and RG-45 Plugs

• Manufacturer: IDEAL

• Crimp Style: Modular Data Crimp





Learn More or Purchase





Part # HDT-48-00PN

• Size: Solid Pins size 12 - 20

• Manufacturer: Deutsch

• Crimp Style: 4 Indent Crimp





Learn More or Purchase





Crimper for Insulated

Terminals



Part # CSA-0760

• Size: 10 - 22 AWG

• Manufacturer: Pressmaster

• Crimp Style: Confined Crimp





Learn More or Purchase





Mobile Tool Frame for use

with 4300 Die Sets



Part # MCT FRAME

• Size: *Multiple (4300 Die Sets)

• Manufacturer: Pressmaster

• Crimp Style: Parallel Confined Crimp





Learn More or Purchase





CimpAll Crimp Tool



Part # PA8000

• Size: Interchangeable Die Sets

• Manufacturer: Greenlee

• Crimp Style:  *Depends of the Die Set





Learn More or Purchase





Omniseal ProXL

Compression Tool



Part # II30-793

• Size: Works with F, BNC, RCA, RG-11, &

            Mini Connectors. RG-6, RG-59, &

            RG-11 Cables

• Manufacturer: IDEAL

• Crimp Style: Compression Crimp





Learn More or Purchase





Field Service Crimper



Part # HDT-1561

• Size: Size 12, 16, & 20 Solid Contacts

• Manufacturer: Deutsch

• Crimp Style:  Single Indent Crimp





Learn More or Purchase





Production Grade Hand

Crimper



Part # HDT-50-00

• Size: Size 12 - 20 Solid Contacts

• Manufacturer: Deutsch

• Crimp Style:  Single Indent Crimp





Learn More or Purchase





Mil-Spec Crimp Tool Frame



Part # AF8

• Size: Requires Turret Heads Size

            12 - 26 AWG

• Manufacturer: DMC

• Crimp Style: 8 Indent Crimp





Learn More or Purchase





Hand Crimp Tool



Part # HDT-48-00

• Size: 12 - 20 AWG

• Manufacturer: Deutsch

• Crimp Style: 8 Indent Crimp





Learn More or Purchase





CRIMPER RENTALS



A WIDE VARIETY OF CRIMPING, STRIPPING, & OTHER TOOLS AVAILABLE  FOR RENT AT WIRECARE.COM

DOES YOUR JOB CALL FOR A TOOL OUTSIDE THE BUDGET?

DO YOU NEED A CRIMPER FOR A ONE TIME PROJECT?

RENTAL TOOLS ARE THE PERFECT SOLUTION



Learn More About Rentals





Modular Data Crimp Diagram

A Modular Data Crimp assists with installation of modular plugs and works with data networking cables and phone circuits.

The Hydraulic Crimp securely crimps fittings

at the ends of hydraulic hoses.

OmniSeal ProXL Compression Tool Crimper Telemaster Modular Plug Ratchet Crimper Tool

10

Handheld Pneumatic Crimper Crimper for Insulated Terminals Mobile Tool Frame for use with 4300 Die Sets CrimpAll Crimp Tool Field Service Crimper Mil-Spec Crimp Tool Frame Production Grade Hand Crimper Hand Crimp Tool

Handheld Pneumatic

Crimper



8

7

6

5

4

3

2

1
